Industrial Data Logger 4G LTE

INTRODUCTION

The product is designed to seamlessly integrate with the IoT and Analytical processing systems. Supporting multiple I/O options, interfaces data logger is a perfect fit to build custom automation solutions. Industrial Data Logger 4.0 can used to build the custom industrial solution for monitoring and controlling PLC and SCADA, HMI, VFD Motors, servo, Valves, energy meter, actuators, relays, encoder, rfid and finger print readers, industrial sensors and many more with below mentioned operational benefits.

Features

12 x isolated Analog Input Channel 0-10V , 0-24v , 4-20mA.
4x isolated Digital input 24V
3x Isolated digital output / PWM 24v
1x Relay ( NO & C)
1x Isolated RS485 for MODBUS RTU communication
1x Isolated Ethernet 10/100Mbps MODBUS TCP Communication
1x USB-device interface for configuring, monitoring and download
1x WIFI / 2G / 4G / LTE wireless communication
Configure and Read Multiple Slave IDs, Selectable Input Register Holding Register & Coil.
Configurable Data type and Conversion method (INT ,Long INT , FLOAT , Double Float & Raw Hex)
Configurable Scaling factor enabling option for Analog channel .
Configurable WIFI / GPRS / 4G / LTE Interface
Configurable data transferring protocol JSON / MQTT and FTP
Support secure communication SSL
Custom Configurable polling interval
Custom Configurable 32 bit counter input
8 GB inbuilt storage
Data Logs and stores its CSV file during network failure
Logger Sends offline data once Network and Server Connected
Configurable Live / Schedule upload offline data
Remote control / Activating Relay / Digital output
Configurable Alarm
OTA (Over The Air) Firmware upgrade for WIFI devices.
LED indicators to indicate Power, Network availability, status & Fault.
Auto Maintain socket / server connection
Easy configurable connectivity for cloud platform AWS / Azure / Google / Oracle / Things board
